Charge and discharge device
The power supply is mainly composed of rectifier transformer circuit, full bridge inversion circuit, positive and negative commutated circuit, voltage stabilizing、voltage limiting circuit, steady flow、current limiting protection circuit. With liquid crystal display along with optimized combination assisting power circuit, the power supply works based on full bridge inversion circuit.
